| 0 |
SWMI/4.2KW-24V |
SWMI/4.2KW-48V |
SWMI/6.2KW-24V |
SWMI/6.2KW-48V |
| Battery Voltage |
24VDC |
48VDC |
24VDC |
48VDC |
| Battery Type |
Lithium / Lead-Acid |
| INVERTER OUTPUT |
| Rated Power |
4200W |
6200W |
| Output Voltage Waveform |
Pure Sine Wave |
| Output Voltage |
AC110V/AC220V
50Hz/60Hz |
| Surge Power |
8400W(5 s) |
12400W(5 s) |
| Efficiency(Peak) |
0.93 |
| SOLAR CHARGER |
| Maximum PV Array Power |
7200W |
7200W |
| MPPT Range@ Operating Voltage |
DC500V |
DC500V |
| PV Array MPPT Voltage Range |
DC45-450V |
DC45-450V |
| Maximum Solar Charge Current |
90A |
90A |
| Maximum Charging Current(AC+PV) |
100A |
100A |
| AC CHARGER |
| PV Maximum Charge Current(AC Input) |
Default 30A/Max 80A |
Default 30A/Max 80A |
| Maximum Charging Voltage(Default/Settable) |
DC28.2V |
DC56.4V |
| Floating Charge Voltage(Default/Settable) |
DC27V |
DC54V |
| PHYSICAL |
| Protection Degree |
IP20 |
| Dimension(W/H/D) |
300/460/120mm |
360/530/160mm |
| Net Weight(kgs) |
9.5 |
12.5 |
| OPERATING ENVIRONMENT |
| Humidity |
5% to 95% Relative Humidity(Non-condensing) |
| Attitude |
<2000m |
| Operating Temperature |
-10℃ - 55℃ |
| Storage Temperature |
-15℃ - 60℃ |
