| TECHNICAL DATA |
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Model No. |
: |
PPI203000 |
| Output |
Capacity |
Rated |
: |
3000W |
| Max |
: |
6000W |
| Waveform |
: |
Pure Sine Wave |
| Frequency |
: |
50Hz |
| Voltage |
: |
AC240V |
| Input |
Voltage |
: |
DC12V |
DC24V |
DC48V |
| Input Volt. Range |
: |
DC10V ~ 15 |
DC20 ~ 30 |
DC40 ~ 60 |
| Conversion Efficiency |
: |
>95% |
| Cooling Method |
: |
Fan |
| Protections |
: |
Over Load Protection |
| : |
Over Temperature Protection |
| : |
Output Short Circuit Protection |
| : |
Recerse Polarity Protection |
| Materials |
: |
Aluminum |
| Ambiment Temperature |
: |
-40¡æ¡« +70¡æ |
| Dimension |
: |
400*230*98mm |
| Dimension(Package) |
: |
446*250*135mm |
| Weight |
: |
5.26kgs |
| Warranty |
: |
3 Years(Battery 1 Year) |
| |
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| ¡¡ |
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Suitable for Camping,Fishing,Etc. |
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| KEY FEATURES |
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| >Pure Sine Wave Output |
| >High Efficiency |
| >Input Over Voltage Prevention |
| >Overload Prevention |
| >Over Temperature Prevention |
| >Output Short Circuit Prevention |
| >Reverse Polarity Protection |
