- SPECIFICATION
- DATA SHEET
- PHOTOMETRY
- APPLICATION
-
| Model No. |
Capacity(W) |
Lighting Resource |
Input Voltage/ Frequency |
Luminous Flux(lm) |
Installation |
Optional Functions |
IP Grade |
| 6000-6500K |
4000-4500K |
2700-3300K |
Emergency Lighting |
Smart Movement Sensor Switch |
| CL64036912 |
12 |
5730SMD |
AC90-265V/ 50-60Hz |
780 |
750 |
720 |
Surfaced |
× |
Details |
44 |
| CL64036918 |
18 |
1250 |
1200 |
1150 |
Details |
| CL64036924 |
24 |
1600 |
1500 |
1400 |
| CL64036930 |
30 |
2100 |
1900 |
1800 |
| |
|
|
|
|
|
|
|
|
|
|
| Benefits |
|
|
|
|
|
|
|
|
|
|
| IP44, |
| High-quality aluminum and lumisheet acrylic plate, with 90% light transmittance |
| Diffused soft lighting effect |
| Will not fade colors, avoids inventory spoilage |
| Smart,unique design |
| Using integrated heat-dissipation aluminum structure improve the heat dissipation greatly |
| 3 years warranty |
| |
|
|
|
|
|
|
|
|
|
|
| Features |
|
|
|
|
|
|
|
|
|
|
| Emits virtually no UV/IR light in the beam |
| Contains no mercury,Lead and other Toxicants |
| Approved by CE&RoHS |
|
-
| Model No. |
Capacity(W) |
Dimension(MM) |
Package(MM) |
Weight(kgs) |
Loading Quantity |
| Net |
Gross |
20'GP |
40'GP |
40'HQ |
| CL64036912 |
12 |
Φ235*80 |
320*320*105 |
0.80 |
1.00 |
2000 |
4200 |
5800 |
| CL64036918 |
18 |
Φ294*80 |
380*380*110 |
1.10 |
1.40 |
1000 |
2300 |
2800 |
| CL64036924 |
24 |
Φ361*80 |
440*440*120 |
1.50 |
1.80 |
800 |
2000 |
2500 |
| CL64036930 |
30 |
Φ426*80 |
500*500*135 |
2.00 |
2.40 |
460 |
920 |
1500 |
| |
|
|
|
|
|
|
|
|
| Operating Temperature |
-40°C To +55°C |
| Beam Angle |
90°~100° |
| Working Temperature |
<55°C(ambient temperature 15°C) |
| Color Rendering Index(CRI) |
>85 |
| Total Harmonic Distortion |
<9% |
| Materials |
Copper PCB,High-quality Aluminum Alloy Body,lumisheet acrylic plate |
| Working Life |
>50,000hours |
|
-
Ideal for damp environment lighting(bathroom,tunnel,etc.). |
|
|
